LiFePO4 Lithium Battery 48V 72V 96V 40AH 200AH 300AH 400AH Rechargeable EV Golf Cart OEM ODM Lithium Ion Battery
Contact Person : Rosa Liu
Phone Number : +86 18975107916
WhatsApp : +8618975107916
| Minimum Order Quantity : | 1-1000 units | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | Wooden case and Carton case | Delivery Time : | 7-15 working days |
| Payment Terms : | T/T | Supply Ability : | 10000 units per month |
| Place of Origin: | Hunan,China | Brand Name: | CLTF |
|---|---|---|---|
| Certification: | CE/ROHS/MSDS/UN38.3 | Model Number: | CLFC-0104 |
|
Detail Information |
|||
| Features: | Cost Effective, Fast Delivery, Stable Structure | Battery Type: | Lifepo4 Battery，li-ion Battery，lithium Battery，NMC |
|---|---|---|---|
| Voltage: | 12V/24V/48V/96V/144V | Capacity: | 120AH, 200AH, 300AH, 400AH, 500AH |
| Application: | Electric Vehicle，electric Boat，electric Yacht,marine | Dimension: | Customized |
| OEM/ODM: | Yes | Keywords: | Lithium Battery,lifepo4 Battery Pack,nmc Battery,marine Battery |
| Battery Case: | Metal | Transport Package: | Foam & Plywood Case |
| Waterproof Standard: | IP67 | ||
| Highlight: | 96V LiFePO4 Lithium Battery,120AH LiFePO4 Lithium Battery,300AH LiFePO4 Lithium Battery |
||
Product Description
LiFePO4 Lithium Battery OEM ODM 100AH 200AH Lithium Ion Lifepo4 Battery Pack Rechargeable 307.2V 50ah For Marine Boat
If you don't see any products that match your requirements please contact us. We may not have it listed on our website yet.
Chalong Fly provides ODM&OEMs with assurances of quality for our products and services. We distribute battery packs and battery cells from many reputable brand names. We manufacture a variety of custom battery packs and power supplies made to customer specifications.
| ELECTRICAL SPECIFICATIONS | |
| Cell Type - Chemistry | Prismatic- LiFePO4 |
| Rated Capacity | 50Ah |
| Rated Voltage | 76.8V |
| Energy | 3.84kWh |
| Resistance | 30mΩ |
| Self Discharge | <4% per month |
| Modules in Series | 4S1P to 307.2V 50Ah battery pack |
| MECHANICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 500*370*160 |
| Weight | 32Kg/module |
| Enclosure Protection | IP67 |
| DISCHARGE/CHARGE SPECIFICATIONS | |
| Discharge Cut-off Voltage | 60V |
| Max Continuous Discharging Current | 50A |
| Peak Discharge Current | 100A for 30 seconds |
| Recommended Discharge Current | 50A |
| CHARGE SPECIFICATIONS | |
| Charging Limited Voltage | 87.6V |
| Max Charging Current | 50A |
| Recommended Charge Current | 25A |
| TEMPERATURE SPECIFICATIONS | |
| Charge Temperature Range | 0~45ºC |
| Discharge Temperature Range | -20~60ºC |
| Recommended Operating Temperature | 15~35ºC |
| Storage Temperature & Humidity Range (Less than 1 month) |
-20~35ºC, 45~75%RH |
| Storage Temperature & Humidity Range (Less than 3 months) |
-10~35ºC, 45~75%RH |
| Recommended Storage Temperature & Humidity Range | 15~35ºC, 45~75%RH |
| OEM | |
| Available on request | yes |
Features of Electric Golf Cart Battery:
1. Lighter weight, smaller size.
2. High-temperature performance.
3. Extremely safe, no explosion, no fire under collision.
4. Strong over-discharge resistance and charge retention.
5. Strong charging acceptance and quick-charging capability.
6. Excellent large current discharge performance especially in startup and climbing.
7. Large capability and long life for all high-power output applications.
8. Environmentally friendly non-toxic, non-contaminating, no rare metal.
9. Low self-discharge and good discharge performance at low temperatures.
