LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack
LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack
Contact Now

LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack

Minimum Order Quantity : 1
Place of Origin: China Brand Name: CLF
Certification: CE Model Number: CLF-R4110

Detail Information
Material: LTO Battery Battery Pack Combination: 6S
Volatge: 11.5V WORK Voltage: 8V~14v
Charge Time: Normal 4h, Fast 1h Capacity: 30~45ah
Maximum Working Current: 6c~15c Cycle: 30000 Times
Weight: 1.3kg Operating Temperature: -20 ℃ --- 65 ℃ (normal Working Temperature)
Storage Temperature: -20 ℃ ~ + 60 ℃ (safe Storage Temperature) Weight: 11KG
Size: 200*140*210mm
Highlight:

Low temperature Lithium titanate battery

,

40AH Lithium titanate battery

,

45AH Lithium titanate battery

Product Description

LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack



PRODUCT PARAMETER



Product Name
11.5V30AH/40AH/45AH/
Material
LTO battery
Function
EV CAR SOLAR
Package
carton
volatge
11.5V
WORK voltage
8-14v
Internal Resistance
≤1mΩ
charge time
Normal 4h, fast 1h
capacity
30~45ah
Maximum working current
6c~15c
Cycle
30000 times
weight
11kg
shell material
plastic
Operating temperature
-20 ℃ --- 65 ℃ (normal working temperature)
Storage temperature
-20 ℃ ~ + 60 ℃ (safe storage temperature)



LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack 0



Features of lithium titanate battery:



High-power charging and discharging capability: fast charging only takes 6 minutes.

Long cycle life: 10 times that of traditional lithium-ion batteries.

Low temperature charge and discharge performance: good condition at low temperature -30℃.

Good safety performance. There is almost no SEI film on the lithium titanate anode, which prevents the battery from overheating and causing fire.

Lithium titanate battery has the characteristics of long life, good low-temperature performance, safe and fast charging and discharging, and can be used in power grid peak shaving, wind energy, and solar energy storage.

LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack 1LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack 2

Advantages of lithium titanate battery:

The use of electric vehicles instead of fuel vehicles is the best choice to solve urban environmental pollution. Among them, lithium-ion power batteries have attracted wide attention from researchers. In order to meet the requirements of electric vehicles for on-board knap ion power batteries, the development of high safety and good rate performance And the long-life negative electrode material is its hot and difficult point.

Currently, commercial lithium-ion battery negative electrodes mainly use carbon materials, but lithium batteries using carbon as negative electrodes still have some drawbacks in their applications:

1. Lithium dendrites are easy to precipitate during overcharging, which will cause short circuit of the battery and affect the safety performance of the lithium battery;

2. It is easy to form SEI film, which results in low first charge and discharge efficiency and large irreversible capacity;

3. That is, the platform voltage of carbon materials is low (close to metal lithium), and it is easy to cause the decomposition of the electrolyte, which brings safety risks.

4. The volume changes greatly in the process of lithium ion insertion and extraction, and the cycle stability is poor. Compared with carbon materials, spinel-type


Li4Ti5012 has obvious advantages:

1. It is a zero-strain material with good cycle performance;

2. The discharge voltage is stable, and the electrolyte is not decomposed, which improves the safety performance of lithium batteries;

3. Compared with carbon anode materials, lithium titanate has a high lithium ion diffusion coefficient (2*10-8cm2/s), and can be charged and discharged at a high rate.

4. The potential of lithium titanate is higher than that of pure metal lithium, and it is not easy to produce lithium crystal branches, which provides a basis for ensuring the safety of lithium batteries.

APPLICATION:
For electric vehicles Agricultural equipment Robot equipment electric wheelchair Fishing equipment Solar energy storage Traffic equipment, street lights AGV trolley Fascia Gun Battery
LTO 12V 40AH 45AH Lithium titanate battery Low temperature power inverter solar large single lithium battery pack 3
